Ilustrativni prikaz
To download 3D models, please login or create an account and request access.
LHD20X20_EN
| EAN kod | 8595057656659 |
| Tarifni broj | 39259020 |
| Težina | 0,1370 kg/m |
| Boja | birch pink |
| Materijal | PVC |
| Materijal bez ulja | yes |
| Samogasivi | 30 s |
| Otpornost na temperaturu | -5 - 60 °C |
| Probna petlja | 850 °C |
| Mehanička zaštita | IK06 |
| Otpornost na udar | 0,5 J |
| Širina | 21 mm |
| Visina | 19 mm |
| Dužina | 2 m |
| Unutarnje područje | 260 mm2 |
| Tolerancija The trunkings are available in lengths with a tolerance of ± 0.5% at 20 ° C. | |
| Klasa reakcije na požar podložnog materijala | A1 - F |
| Vrste zaštite | IP 40 |
| Standardi | ČSN EN 50 085-1 |
| Opis paketa | package - cardboard |
Standard shape. Designed for wall or ceiling mounting. Double lock on lid increasing the trunking’s rigidity and ensuring stronger cover fixation. 8824/12 transition branching intended for transition to the LP 80X25 trunking.
